MDT Pressure Analysis Workbook — Field-Ready Template for Formation Evaluation Engineers
Wireline MDT and RCI station analysis: pressure–TVD gradients, fluid contacts, mobility-based permeability estimates, and a one-page summary — all formula-driven Excel.
TITLE
MDT Pressure Analysis Workbook — Field-Ready Template for Formation Evaluation Engineers
PRICE
$79 USD — one-time purchase
TAGLINE
Wireline MDT and RCI station analysis: pressure–TVD gradients, fluid contacts, mobility-based permeability estimates, and a one-page summary — all formula-driven Excel.
WHO IT'S FOR
Reservoir and petrophysics engineers, geoscientists, and consultants who interpret wireline formation tester (MDT, RFT, RCI) pressure and mobility data for contacts, zonation, and reports.
WHAT IT DOES
Turns raw station MD, TVD, pressure, temperature, mobility, and quality flags into inter-station gradients, a pressure–TVD plot with adjustable fluid-gradient lines and GOC/OWC markers, mobility–depth and estimated permeability by zone, and a dashboard with contacts, column height, and data-quality counts. No VBA or add-ins.
TABS INCLUDED (5)
• Instructions & Legend — color codes, workflow, compatibility • Raw Data Input — single entry table; validation on zone, quality, supercharge • Pressure Gradient Plot — gradients; supercharged points excluded; pressure vs TVD chart; contact annotation • Mobility Analysis — mobility vs TVD; k from mobility and viscosity; tight-zone flag; zone statistics • Summary Dashboard — contacts, thickness, pressure stats, quality summary, analyst notes
KEY FEATURES
• Supercharged stations excluded from gradient fit and flagged on the plot • Fluid-gradient lines and contact interpretation on the main pressure–TVD figure • Mobility cutoff for tight-zone identification; zone min/avg/max mobility and k • 296 native Excel formulas; Excel 2016 through Microsoft 365; Windows and Mac
TECHNICAL SPECS
• Excel 2016+ compatible — no plugins or macros • 296 formulas; 15 sample stations included for reference • Adjustable fluid gradient and viscosity assumptions • Color-coded by fluid zone; print-ready layouts
SHOP COPY
5-tab MDT workbook: station input, automatic pressure–TVD gradient and contacts, mobility and permeability by zone, and summary dashboard for field-ready documentation.
SUGGESTED TAGS
MDT, RFT, RCI, formation tester, pressure gradient, wireline, petrophysics, fluid contacts, mobility, Excel template, petroleum engineering
ABOUT RESERVOIR RISK SOLUTIONS
Built by petroleum engineers for petroleum engineers. All workbooks require only Microsoft Excel (2016+) — no plugins, no subscriptions. reservoir-risk-solutions.com
What you get
- Instant workbook access after payment in your Excel Library
- Formula-driven worksheet designed for petroleum workflows
- No recurring fees and no plugin requirements
FAQ
Is this a one-time purchase?
Yes. One-time price for the workbook. No subscription.
Is this the same as the core por–perm rock-typing template?
No. This workbook is for wireline MDT/RCI pressure and mobility. Use the Por-Perm Crossplot Interpreter for core-based porosity–permeability rock typing.
